Sale!

₹138,500.00

Drawn arc inverter technology reduces the weight by 50 % compared to welding units with transformer technology.
Minimized energy consumption – energy needed is reduced by 50 % compared to standard welding units with transformer technology.
Specifically designed for thicker sheets of about 2 mm or higher
“Energy package for larger studs, used on construction sites and workshops”

Drawn arc Torch
Heavy duty gun for construction sites.
Length compensation for stable welding results.

Features

➢ Joining of stud-type welding elements with a diameter 2 to 28 mm onto thin sheets, min. 0.5 mm. Mild steel, stainless steel and aluminium.
➢ "Short Cycle (SC)
➢ drawn arc stud welding"
➢ "High current, shorter
➢ duration of welding time"
➢ "The welding sequence is the same as the sequence of drawn arc welding (ARC),
➢ however, with relatively
➢ higher currents and shorter welding times (max. 100 ms).
➢ The short cycle drawn arc stud welding is very suitable for stud diameters up to 28 mm on thin metal sheets."
➢ The short and clean welding process does not require any type of machining grinding.
Catalog

https://www.ambitionweld.com/wp-content/uploads/2023/04/JSD-25.pdf
PARAMETER JCD-12 PARAMETER JSD-16 PARAMETER JSD-19 PARAMETER JSD-22 PARAMETER JSD-25 PARAMETER JSD-28
Input voltage V AC 415 + 15% Input voltage V AC 415 + 15% Input voltage V AC 415 + 15% Input voltage V AC 415 + 15% Input voltage V AC 415 + 15% Input voltage V AC 415 + 15%
Frequency 50/60 Hz Frequency 50/60 Hz Frequency 50/60 Hz Frequency 50/60 Hz Frequency 50/60 Hz Frequency 50/60 Hz
Stud welding range M3-M12 Stud welding range M5-M16 Stud welding range M5-M19 Stud welding range M5-M22 Stud welding range M5-M25 Stud welding range M5-M28
Power Supply 30 KVA Power Supply 55 KVA Power Supply 90 KVA Power Supply 95 KVA Power Supply 95 KVA Power Supply 130 KVA
Weld Time 10 – 500 Sec Weld Time 10 – 1600 Sec Weld Time 10 – 2500 Sec Weld Time 10 – 2500 Sec Weld Time 10 – 2500 Sec Weld Time 10 – 2500 Sec
Welding Speed 10 pcs/ min Welding Speed 6-18 pcs/ min Welding Speed 6-21 pcs/ min Welding Speed 6-21 pcs/ min Welding Speed 6-21 pcs/ min Welding Speed 6-21 pcs/ min
Phase Three Phase Three Phase Three Phase Three Phase Three Phase Three
Material M.S , S.S , Aluminium , Brass Material M.S , S.S , Aluminium , Brass Material M.S , S.S , Aluminium , Brass Material M.S , S.S , Aluminium , Brass Material M.S , S.S , Aluminium , Brass Material M.S , S.S , Aluminium , Brass
Current 300-900 Amps Current 200-1600 Amps Current 300-1800 Amps Current 300-2400 Amps Current 300-2500 Amps Current 300-2500 Amps
Cooling Air Cooling Air Cooling Air Cooling Air Cooling Air Cooling Air
Dimension(L*W*H) 520*410*490 Dimension(L*W*H) 550*410*590 Dimension(L*W*H) 820*600*780 Dimension(L*W*H) 925*600*780 Dimension(L*W*H) 965*600*780 Dimension(L*W*H) 1025*600*780
Weight 185 kg Weight 215 kg Weight 295 kg Weight 370 kg Weight 370 kg Weight 390 kg
